Ship via: Can Ship UPS
Area of application: For interlocking shelves in board material
Features: 2 wedged ribs with twin grooves
Finish: Nickel-plated
For drill hole Ø: 5 mm
Installation: For insert fitting
Load bearing capacity: 12.5 kg per piece, i.e. 50 kg load bearing capacity when using 4 shelf supports tested to DIN EN 16337:2013-08 with 1.7 kg plate for impact test kg
Load bearing capacity per item: 12.50 kg
Load bearing capacity with 4 shelf supports: 50.00 kg
Material: Zinc die-cast
Note: Ribs anchor themselves in the system holes due to pressure from the shelf, which is an important feature for areas prone to earthquakes.
Note on load bearing capacity: Load bearing capacity per item, i.e. load bearing capacity of 50 kg when using 4 shelf supports tested with 1.7 kg plate for impact test in compliance with DIN EN 16337:2013-08
Version: With twin grooves
