Richelieu SH1SQ90W195 Riveo Pro Square GTW Hinge with Full BackplateRichelieu SH1SQ90W195 Riveo Pro Square GTW Hinge w/ Full Backplate is a premium self-closing hinge designed specifically for installing glass doors against adjacent walls. This versatile hinge is part of the Riveo Pro collection, known for its extensive range of styles and finishes, making it an ideal choice for various projects, including corner showers and door-and-panel configurations. Constructed from solid brass with a stainless steel pin and spring, this hinge is durable and ensures a long-lasting performance. It accommodates tempered glass thicknesses ranging from 5/16 to 13/32 inches, allowing for flexibility in your design choices. Depending on the model selected, installation may require either "mouse-ear" or square-type glass milling. The hinge supports a maximum glass weight of 79.4 lbs when using two hinges, and up to 121 lbs with three, while allowing glass widths of up to 30 inches and 36 inches, respectively. Finished in brushed nickel, the Richelieu SH1SQ90W195 not only adds functionality but also enhances the overall aesthetic appeal of your space. With wall-mount installation, this hinge stands out as a reliable and stylish option for both professionals and discerning homeowners alike.
Riveo Pro Square GTW Hinge w/ Full Backplate
This self-closing hinge is designed to install a glass door to an adjacent wall.
Riveo Pro offers the widest range of styles and finishes to complement any project.
Application
Designed to be used with several thicknesses of tempered glass.
Regular-duty models require "mouse-ear" type glass milling for installation.
Heavy-duty models require square type glass milling for installation.
Light-duty models require "mouse-ear" type glass milling for installation.
Attributes
Ship via: Can Ship UPS
Angle: 90°
Application: Corner Shower, Door, Door and Panel
Brand: Riveo
Collection: Riveo Pro
Finish: Brushed Nickel
Glass Thickness: 5/16 to 13/32 in*
Hinge Type: Standard
Material: Solid Brass/Stainless Steel Pin & Spring
Max. Glass Weight for 2 Hinges: Max. 79.4 lb*
Max. Glass Weight for 3 Hinges: Max. 121 lb*
Max. Glass Width for 2 Hinges: Max. 30 in
Max. Glass Width for 3 Hinges: Max. 36 in
Mounting Method: Wall Mount
Product #: SH1SQ90W195
Product №: SH1SQ90W195
Style: Square
Unit 1: carton - 10
Unit 2: case - 20
Usage: Regular
