Richelieu WEBKIT1243302 HAWA-Junior Z Series Straight Sliding Door SystemRichelieu WEBKIT1243302 HAWA-Junior Z Series Straight Sliding Door System offers a sophisticated solution for wood doors weighing up to 100 kg, making it an ideal choice for both commercial and premium residential applications. This standard straight-sliding system features a surface top-mount two-way suspension plate, ensuring durability and ease of installation. The system is designed with an integrated track stopper, equipped with an adjustable retaining device to effectively resist door bounce back, enhancing safety and functionality. For added convenience, the optional SoftMove closing system ensures a gentle and quiet door operation. The versatile track options support various configurations including single sliding, bi-parting, and bypassing applications, allowing adaptability to different spaces. Select from multiple track types to best suit your design needs, including a basic anodized track, ceiling mount track, or wall mount track for a sleek clip-on fascia. Engineered for smooth and quiet performance, the premium trolleys ensure a seamless experience. Specifically designed for doors with a thickness ranging from 1 3/16 to 1 25/32 inches and a maximum height of 10 feet, this system is perfect for closets, pocket doors, and other interior applications. Please note that installation requires a groove of 12 mm x 20 mm at the bottom of the door for proper guiding.
HAWA-Junior Z Series Straight Sliding Door System
The HAWA-Junior Z Series, featuring the HAWA-Junior 40/Z, Junior 80/Z, and Junior 100/Z is a standard straight-sliding system for wood doors weighing up to 100 kg.
Features:
- Surface top-mount two-way suspension plate
- Integrated track stopper with adjustable retaining device to resist door bounce back
- SoftMove closing system (sold separately)
- Versatile track options for single sliding, bi parting, and bypassing applications
- Select from the following tracks:
a) Basic anodized track
b) Ceiling mount track for clip-on fascia
c) Wall mount track for clip-on fascia
- Smooth and quiet premium performance trolleys
- Flexible door installation
The HAWA-Junior Z Series is an ideal solution for commercial and premium residential projects. For use with doors between rooms, premium closets, and pocket doors.
IMPORTANT: Use metric dimensions for greater accuracy during installation. Cut a groove 12 mm x 20 mm at the bottom of the door for bottom guide.
Attributes
Ship via: No UPS - Common Carrier Only
Application: Closet and Walk-In Closet, Standard Access Door, Pocket Door
Brand: Junior
Brand Model: Hawa Junior
Detailed Door Movement: Single sliding
Door Height: Max. 3 050 mm
Door Installation: Top Hung
Door Material: Wood
Door Movement: Straight Sliding
Door Thickness: 30 to 45 mm
Door Width: 1 030 to 1 500 mm
Finish: Anodized Aluminum
Function: Sliding Door
Groove Needed for Guiding System: Yes
Length - Overall Dimensions: 9 ft 10 in*
Load Capacity: 90.4 to 176 lb*
Manufacturing Material: Aluminum
Number of Doors: 1
Overall Length: 3 000 mm
Product #: WEBKIT1243302
Product №: WEBKIT1243302
Roller Position: Upper
Shipping Limitations: Some products exceed standard small package size regulations and may incur additional fees. Items measuring 84" or more could require extra charges or LTL shipping. Please keep this in mind when ordering, and contact customer service for more details.
Soft- Close Type: Two Soft-close
Soft- Closing: Yes
Stopper: Two
Track Material: Anodized Aluminum
Track Mounting: Wall Mount
Weight Capacity per Door: 41 to 80 kg
