Richelieu WEBKIT1243444 TERNO STEP 50 FLUID Series

Richelieu WEBKIT1243444 TERNO STEP 50 FLUID Series

Automatic clip-on suspension plate The TERNO STEP 50 FLUID Series is a standard straight sliding wood door system for wood doors weighing up to 50 kg each.

Features:
- Automatic clip-on suspension bracket for quick, tooless door installation
- Choice of hardware types

a) 2 shock absorber stops
b) 2 soft close mechanisms

- 50 kg soft close is ADA / Barrier-Free compliant with a low pull force of 1.6 kg
- Track options for ceiling mount and wall mount
- Clip-on anodized aluminum fascia options for 35 mm and 45 mm thick doors
- Optional clips for wood fascia supplied by the Contractor

The TERNO STEP 50 FLUID Series is an ideal solution for residential and commercial applications including multi-unit projects for pocket doors, access doors between rooms and room dividers.

IMPORTANT: Use metric dimensions for greater accuracy during installation.
Groove is required at the bottom of the door, see mounting instructions for details.
Optional two-part floor guide can be purchase separately to avoid cutting a groove.

Advantages and benefits

- Quick and simple low-cost installation
- Minimal effort required to overcome the automatic soft close mechanism when opening the door

Important information

IMPORTANT: Use metric dimensions for greater accuracy during installation.
Groove is required at the bottom of the door, see mounting instructions for details.
Optional two-part floor guide can be purchase separately to avoid cutting a groove.

- Pictures provided for visual reference only: actual product may vary.
- All required hardware should be ordered and obtained prior to initiating fabrication or installation work. Please verify that the parts and quantities listed in your order are correct before proceeding to checkout.
- Always use instructions provided by the manufacturer, as included with the product. Manufacturer reserves the right to amend, modify, or otherwise supplement any previously issued product and/or technical information, as deemed required from time to time, without prior notice.
- The documentation, drawings, and instructions on this page apply to the system described on this page only. Richelieu expressly declines all responsibility for any design or construction that combines this system with systems from this same manufacturer or systems from other manufacturers.
- Installation of the product shall be executed by qualified individuals only, always ensuring that each product is securely installed using proper fixation methods, as appropriate for each applicable substratum. We trust that anyone installing these products has the required skills, knowledge, and experience. Richelieu expressly disclaims any liabilities for results obtained through improper use or installation.
- Always remove debris/dust/residue (sawdust and/or aluminum) from all tracks and guide channels using a dry cloth during installation and before operating the system.
- Never spray lubricant on this product.

Resources

• Instructions
